An ESD chair for electronics assembly, labs and other ESD-controlled work areas: a static-dissipative seat and back in vinyl or fabric, ESD casters or glides, two height ranges, and a 300 lb capacity.
- Static-dissipative seat, back and casters. The seat and back are covered in electro-static dissipating vinyl or fabric over molded foam, and the standard casters are ESD casters. ESD models are tested for static-dissipative performance in accordance with ANSI/ESD STM12.1, at a point-to-groundable-point resistance below 1.0 x 10^9 ohms. Testing is in-process sampling, not third-party certification. Static-dissipative performance depends on a controlled environment held at approximately 74°F with relative humidity of at least 15%.
- Two height ranges. Medium Bench Height 21.5–29 in. or High Bench Height 26.25–36 in., measured from the floor to the top of the seat. High Bench Height comes with a 20 in. chrome foot ring with knob lock.
- Padded seat and back. An 18 in. wide, 16 in. deep seat, 2.5 in. thick, and a 16.5 in. wide, 11.5 in. high back. Vinyl in Black or Royal Blue; fabric in Black or Navy Blue.
- Options to fit the task. Add six-way adjustable arms that move up and down, in and out, and twist toward or away from you; a seat tilt that locks 8° forward or 3° back; or both. ESD Hard Floor Casters come standard; ESD glides are also available. Polished cast-aluminum base.
- 15-Year Warranty · Lifetime Cylinder Guarantee. 15 years against defects in the frame and structure, 3 years on the seat and back including static-dissipative performance, and a replacement gas cylinder at no charge for the life of the chair.
| Seat height | Medium Bench Height 21.5–29 in. (ESDC2) · High Bench Height 26.25–36 in. (ESDC3) |
|---|---|
| Height control | Pneumatic height adjustment |
| Seat | 18 in. wide, 16 in. deep, 2.5 in. thick |
| Back | 16.5 in. wide, 11.5 in. high, 2.5 in. thick |
| Upholstery | Electro-static dissipating vinyl (Black or Royal Blue) or fabric (Black or Navy Blue) over molded polyurethane foam |
| Options | Six-way adjustable arms · seat tilt, 8° forward and 3° back, locks in place |
| Base | 27 x 27 in., polished cast aluminum |
| Feet | ESD Hard Floor Casters (standard; static-dissipative, dual-wheel, non-marring) or ESD glides (static-dissipative, non-marring, no wheels) |
| Foot ring | High Bench Height: 20 in. chrome foot ring with knob lock, included |
| Weight capacity | 300 lb |
| Chair weight | 33–36 lb; 43–46 lb with arms |
| Shipping | Ships within 2–3 business days; free UPS Ground in the contiguous US |
| Assembly | Ships in one box (25 x 15 x 25 in.); pressure-fit assembly, no tools; a QR code on the box opens the instructions |
| Warranty | 15-Year Warranty · Lifetime Cylinder Guarantee: 15 years against defects in the frame and structure, 3 years on the seat and back including static-dissipative performance, and a replacement gas cylinder at no charge for the life of the chair |
Which height do I need?
Medium Bench Height adjusts 21.5–29 in. and High Bench Height 26.25–36 in., measured from the floor to the top of the seat. High Bench Height includes the foot ring.
Can we pay by purchase order?
Yes. Choose Purchase Order / Invoice at checkout. W-9 on request; tax-exempt orders accepted.
How fast does it ship?
Ships within 2–3 business days. Free UPS Ground shipping in the contiguous US.
Casters or glides?
ESD Hard Floor Casters come standard. ESD glides have no wheels. Both are static-dissipative.
Does it arrive assembled?
It ships boxed and goes together with press-fit parts. A QR code on each box opens the assembly instructions (also under Additional Resources).
Can one order mix heights, colors or feet?
Yes. Add each build to the cart, then check out once.
Can we send it back?
Yes. Get any chair or stool back to us within 30 days of delivery, and the return is on us. It needs to come back new and resellable, with all the parts and pieces in the original box.
Need a written quote?
Request a written quote, sent within one business day.
